OCTO 1000 Standard(OT1000S)

€2,399.00
OCTO 1000 Standard(OT1000S)

OCTO 1000 Standard(OT1000S)

€2,399.00
Translation missing: de.products.product.description

1000mm Standard -Type OCTO Airframe Kit



Specification

-Diameter : 1000mm (motor to motor)

-Weight : 1600g

-Center Frame Size : 240mm X 240mm



Recommended Equipment :

-ESC : 40~ 45 A Opto ESCs.

-Propeller : up to 14 inch, 14 inch recommended

-Flight Controller : DJI A2 or MikroKopter FlightCTRL 2.5

-Cameras : RED Epic, Canon 5D / C100

-Battery : 6s LiPO with 10000+mAh



Suitable Camera Gimbals :

- Freefly Systems: MoVi MR, 2 and 3 axis Cinestar gimbal

- Photo Higher: Pro Mount 200, Halo 2000, Halo 3000

- DJI Zenmuse Z15



This product is a pure kit.

Landing Gear and Electronic equipment is not included.



Items Included:

    • 4 X Inner Arms
    • 8 X Outer Arms
    • 1 X TOP Center Plate
    • 1 X Bottom Center Plate
    • 2 X Battery Tray
    • 1 X GPS Plate
    • 4 X Boom Clamp Set
    • 16 X Cross Member
    • 10 X Hub Connector
    • 8 X Motor Mount Assembly
    • 1 X Rail Mount Assembly for Gimbal
    • 4 X Velcro Battarry Strap
    • Screws & Nuts
